9. Options
73
9.8 Motor Reversed to Left, Motor Reversed to Right
“ML” indicates that the motor is reversed to the left, while “MR” indicates that the motor is reversed to the right,
as viewed from the motor.
This option can be specified for the motor reversing types SA4R, SA5R, SA6R, SA7R, SS7R and SS8R.
9.9 Changing the Cable Exit Direction
The cable exit direction is changed. The model numbers are as follows:
� A1S: Cable exit from left side
� A1E: Cable exit from rear left
� A3S: Cable exit from right side
� A3E: Cable exit from rear right
9.10 Changing the Motor Reversing Direction (Left/Right) and Cable Exit Direction
Whether the motor is reversed to the left or right, and the cable exit direction, is changed.
The model numbers are shown below.
The specified motor reversing types are RCS3/RCS3P-SA8R and SS8R.
ML
Left
MR
Right
Motor reversed to right
Model number: MRE/MRS
Motor reversed to left
Model number: MLE/MLS
Exit from right side
Model number: MRS
Exit from right side
Model number: MRE
Exit from left side
Model number: MLE
Exit from left side
Model number: MLS
Model number: A3S
(exit from right side)
Model number: A3E
(exit from rear right)
Model number: A1E
(exit from rear left)
Model number: A1S
(exit from left side)
(Cable exit direction)
* All directions are
based on a top view.
