12.
Appendix
210
12.1.10 RCS2-SA4R
50 100 150 200 250 300 350 400
L 209.7 259.7 309.7 359.7 409.7 459.7 509.7 559.7
M 122 172 222 272 322 372 422 472
N 50 100 100 200 200 300 300 400
P 35 85 85 185 185 285 285 385
R 22 22 72 22 72 22 72 22
U � 1 1 2 2 3 3 4
m 4 4 4 6 6 8 8 10
2-�3H7, depth 5
At least 100
or more
Reference
surface
Stroke
4-M3, depth 7
Detail view of A
Home
m-M3, depth 5
Cable joint
connector
Slider height: 40.5
Bottom surface of base
A
ct
ua
to
r w
id
th
:4
0
Slit
For position
adjustment
� 8 hole
Detail of slit for slider
position adjustment
(Detail of reference
surface of actuator)
Detail of oblong hole
Reference position for
Ma moment offset
End face of base
End face of base
Oblong hole, depth 5 from bottom
surface of base
(pitch of �3 hole and oblong hole)
(pitch of �3 holes)
2-�3H7, Depth 5 from bottom surface of base
End face of base
(137 with brake)
End face of base
4-�3.6
� 6.5, deep
counterbore,
depth 3.7 (for
actuator
installation)
(to
le ra
nc
e fo
r re
ame
d
ho
le p itch
� 0.
02
mm)
50 (stroke 50)
U x 100 P (stroke other than 50)
Stroke 0 00 0 00 0 00 0 00
L 0. . 0. . 0. . 0. .
M
N 0 00 00 00 00 00 00 00
P
R
U -
m 0
Weight
[kg]
without
brake
0. 0. .0 . . . . .
with
brake
. . . . . . . .
