11. Maintenance and Inspection
99
[4] When proper clearances are obtained between the slider body and stainless sheet and an absence of
contact between the two is confirmed, tighten the two screws on the loose end alternately, and then finally
tighten all screws to a uniform torque to securely affix the stainless sheet. If the screws are not tightened
uniformly, the sheet may meander or lift.
Stainless-sheet retainer cover mounting bolt
