7. Setting the Home
67
7.5.2 ECON or SCON Controller
(1) Open the position edit screen.
On the PC software screen, click , select [Select Position No.], and then click [OK]. The following
screen will appear.
(2) Compare the current position and the position of the desired position number you have selected.
Click this button and select a desired position number on the
position edit screen.
The current position
is displayed here
Point number
[2] Move the actuator
in steps.
[1] Select a desired
position.
