Page 25
16
2. Motor Straight Type (Standard) RCS3(P)
�
Coupling Type
(SA8)
�
Coupling Type (SS8)
Stainless Sheet
Right Side
Opposite Motor End
Motor End
Left Side
Side Cover
Base
Bearing Housing
Slider
Motor Unit
Cable
Slider Cover
Front bracket
Side Cover
Right Side
Opposite Motor End
Motor End
Base
Left Side
Cable
Bearing Housing
Slider
Motor unit
Front bracket
Screw cover
