21
Stainless Sheet
Side Cover
Right Side
Opposite Motor End
Motor End
Left Side
Cable
Slider
Slider Cover
Base
Stainless Sheet
Side Cover
Right Side
Opposite Motor End
Motor End
Left Side
Cable
Slider Cover
Base
Slider
Slider
Reversing Bracket
Reversing Bracket
7. Motor Reversing Type (Slider Roller Specification) RCS3 (P)
� SA8R (Option model number: SR)
� SS8R (Option model number: SR)
Caution: The cable directly connected to the actuator is not robot cable even when ordered
with robot cable option. When designing, please be sure not to give repeated
bending loads to this cable.
The robot cable is applicable only to the connecting cables.
Motor Unit
Front bracket
Motor Unit
Front Bracket
