11. Maintenance and Inspection

6) Disconnect the encoder relay cable from the actuator cable.

The encoder relay cable will be attached to the actuator cable for replacement in Step 17).

7) Detach the motor cover from the actuator cable.

Encoder Relay Cable

Motor cover

Actuator cable
