12.
Appendix
209
12.1.9 RCS2-SA6D
50 100 150 200 250 300 350 400 450 500 550 600
L 304.5 354.5 404.5 454.5 504.5 554.5 604.5 654.5 704.5 754.5 804.5 854.5
A 198 248 298 348 398 448 498 548 598 648 698 748
N 81 131 181 231 281 331 381 431 481 531 581 631
P 66 116 166 216 266 316 366 416 466 516 566 616
R 81 31 81 31 81 31 81 31 81 31 81 31
U 1 2 2 3 3 4 4 5 5 6 6 7
m 6 8 8 10 10 12 12 14 14 16 16 18
Stroke
2-�5H7, effective depth 6
Cable joint
connector
At least 100
or more
Reference
surface
4-M5, depth 9
Stroke
Detail view of A
Home
m-M5, depth 8
Reference position for Ma
moment offset
Detail of oblong hole
Oblong hole, depth 5 from bottom
surface of base
Brake Dimensions
R: Brake cable exit from right
E: Brake cable
exit from end
L: Brake cable
exit from left
3-�4H7 Depth 5 from bottom surface of base
(pitch of �4 holes)
(pitch of �4 hole and oblong hole)
(pitch of �4 holes)
Bottom surface of base
(to
le ra nc
e
fo r re
ame
d
ho
le p itch
� 0.
02
mm)
End face of base
Stroke 0 00 0 00 0 00 0 00 0 00 0 00
L 0. . 0. . 0. . 0. . 0. . 0. .
A
N
P
R
U
m 0 0
Weight
[kg]
without
brake
. . . . . . . . . . . .
with
brake
. . .0 . . . . .0 . . . .
