20
Stainless Sheet
Side Cover
Right Side
Opposite Motor End
Motor End
Left Side
Cable
Base
Slider
Stainless Sheet
Side Cover
Slider
Slider Cover
Right Side
Opposite Motor End
Motor End
Left Side
Cable
Base
Reversing Bracket
Reversing Bracket
Motor Unit
6. Motor Reversing Type (Standard) RCS3 (P)
� SA8R
� SS8R
Caution: The cable directly connected to the actuator is not robot cable even when ordered
with robot cable option. When designing, please be sure not to give repeated
bending loads to this cable.
The robot cable is applicable only to the connecting cables.
Front Bracket
Motor Unit
Front Bracket
