12.
Appendix
220
12.1.20 RCS2CR-SS7C
50 100 150 200 250 300 350 400 450 500 550 600
L 364 414 464 514 564 614 664 714 764 814 864 914
A 226 276 326 376 426 476 526 576 626 676 726 776
B 0 40 90 140 190 240 290 340 390 440 490 540
C 90 40 90 140 190 40 90 140 190 40 90 140
D 6 8 8 8 8 12 12 12 12 16 16 16
M 1 1 1 1 1 2 2 2 2 3 3 3
N 0 1 1 1 1 2 2 2 2 3 3 3
Stroke
2-�5H7, depth 10
Cable joint
connector
4-M5 depth 10
At least 100 or more
Home
(Stroke)
D-M5 depth 8
(to
le ra
nc
e fo r re
ame
d
ho
le p
itch
� 0. 02
mm)
(Pitch of reamed holes
and oblong holes)
90 at stroke of 50
(Pitch of reamed holes )
(Pitch of reamed holes ) (Pitch of reamed holes )
Reference position for Ma
moment offset
Detail of oblong hole
Brake Dimensions
Oblong hole, depth 6 from
bottom surface of base
4-�4H7
Depth 6 from bottom surface of base
(3-�4H7 at stroke of 50, depth 6 from bottom surface
of base)
Applicable tube outer diameter: �8
Stroke 0 00 0 00 0 00 0 00 0 00 0 00
L
A
B 0 0 0 0 0 0 0 0 0 0 0 0
C 0 0 0 0 0 0 0 0 0 0 0 0
D
M
N 0
Weight [kg] . . . .0 . . .0 . . .0 . .
