5. Installation

57

��

��

��

��

��

��

��

��

2-�3H7, depth 5

4-M3, depth 7

5.6.2

Using a Slider Spacer (Optional)

(Optional for SA4 Type)

For the SA4 type, a slider spacer is available as an option.

The figure below shows the positions of load-mounting holes in actuators with a slider spacer.
