Luminex 100 IS User Manual, Version 2.1 User Manual
Page 33
x
MAP Technology
Installation
PN 89-00002-00-061 Rev. A
4 - 7
Figure 8. The XYP Instrument Sampling Probe
6. Re-install the light housing by pushing until it snaps into place.
7. Install the shield to cover the sampling probe area. This shield
should only be removed for making adjustments to the probe.
Figure 9. The Clear Plastic Shield
Sampling probe
The shield is the
clear plastic piece
covering this
area.
