PN 89-00002-00-061 Rev. A A - 1
Luminex Sheath Delivery System
Intended Use
The Luminex Sheath Delivery system (SD™ system) is designed as
an accessory for use with a UL-listed Luminex 100 analyzer. With
the SD system, you can run samples continuously without needing to
refill sheath bottles. The SD system automatically draws sheath from
a non pressurized bulk sheath container to constantly maintain a
reservoir of pressurized sheath fluid. A single 20 liter sheath
container provides enough fluid for 48 hours or more of normal
operation.
Specifications
General
• Ambient temperature: 15°C to 30°C (59° to 86°F)
• Humidity: 20% to 80%, noncondensing
• Altitude: designed to operate at up to 2400m (7874 feet) above
mean sea level
• Physical dimensions: 20 cm (8 inches) W x 30 cm (11.75 inches)
D x 24.75 cm (9.75 inches) H
• Weight: 9 kg (20 lbs)
• UL installation category: UL Installation Category II, as defined
in Annex J of UL 3101-1
• Pollution degree: UL Pollution Degree 2, as defined in Section
3.7.3.2 of UL 3101-1
Power
• Input voltage range: 100-240 VAC, 0.4 Amps, 47-63 Hz
• AC inlet fuse: 2 Amp, 250 Volts, time delay
Hardware
The SD includes these parts:
•
SD system device
A
