Eclipse Upgrade Reference Manual
Clear-Com Communication Systems Page 13 of 155 Part Number: 810377Z Rev 6
3 Eclipse-Omega & Eclipse-Median Configuration/CPU Card
3.1 Important Information
Carefully read the following important information BEFORE commencing any
upgrade of the Omega or Median configuration cards.
Before attempting any upgrade, ensure that anti static precautions are taken,
as Eclipse items are sensitive to static discharges.
Updating the Omega & Median Configuration card Boot ROM
3.2.1 Required Equipment
1. 2 MBit PROM device – ST M27W201 or equivalent.
2. PROM Programming unit.
3. PROM programming software appropriate for the unit.
4. Appropriate ‘S’ record file for Eclipse Configuration Card boot.
InstallCD\Omega-Median\710620Z – Config Boot PROM\710620Z.s
3.2.2 Upgrade Steps
1. Ensure that the PROM device to be programmed is empty.
2. Program the PROM device with the appropriate file according to the
instructions for the PROM programmer being used.
3. Confirm that the checksum of the programmed device matches that
detailed in the Eclipse release notes.
4. Remove the existing PROM device from the configuration card – see
1.1 – Figure 2.
5. Insert the newly programmed PROM device taking care to ensure the
correct polarity of the device.
6. Observe static procedures.
