E DITING I NTEGER T AGS V LINX F IELDBUS G ATEWAY M ANAGER U SER M ANUAL
P AGE 66
• The Group Digits property is used to indicate whether decimal values should
have the digits before the decimal place grouped in threes, and separated with
commas. Similar separation is performed on other number bases, using
groupings and separators appropriate to the selected radix.
• The Prefix property is used to specify a translatable string that will be displayed
in front of the numeric value. This is typically used to indicate units of measure.
• The Suffix property is used to specify a translatable string that will be displayed
after the numeric value. This is also typically used to indicate units of measure.
T
HE
C
OLORS
T
AB
The Colors tab of an integer tag contains the following properties…
• The Default property is used to define the color pair that will be used to display
the tag when its value is less than the Limit 1 property.
• The remaining properties define limits, and color pairs, that will be used to
display the tag when its value is greater than the corresponding limit, and less
than the next limit. If the next limit is zero, the color pair will be used whenever
the tag’s value exceeds the specified limit.
