Chapter 7 System Information
IES-612-51A User’s Guide
88
The following table describes the labels in this screen.
Table 11 System Info
LABEL DESCRIPTION
System Name This field displays the device's model name.
ZyNOS F/W Version This field displays the version number of the device’s current firmware including
the date created.
DSP Code Version This field displays the Digital Signal Processor firmware version number. This is
the modem code firmware.
Hardware Version This is the version of the physical device hardware. This field may be blank.
Serial Number This is the individual identification number assigned to the device at the factory.
This field may be blank.
Ethernet Address This field refers to the Ethernet MAC (Media Access Control) address of the
device.
Hardware Monitor
Enable Select this check box to turn the hardware monitor on or clear it to turn the
hardware monitor off.
Temperature Unit Select C to display all temperature measurements in degrees Celsius. Select F
to display all temperature measurements in degrees Fahrenheit.
Temperature Each temperature sensor can detect and report the temperature. Temperature
sensor 1 is near the DSL chipset. Temperature sensor 2 is near the central
processing unit. Temperature sensor 3 is at the hardware monitor chip.
Current This shows the current temperature at this sensor.
MAX This field displays the maximum temperature measured at this sensor.
MIN This field displays the minimum temperature measured at this sensor.
Average This field displays the average temperature measured at this sensor.
Threshold (Low) This field displays the lowest temperature limit at this sensor.
Threshold (Hi) This field displays the highest temperature limit at this sensor.
Status This field displays Normal for temperatures below the threshold and Over for
those above.
Voltage(V) The power supply for each voltage has a sensor that can detect and report the
voltage.
Current This is the current voltage reading.
MAX This field displays the maximum voltage measured at this point.
MIN This field displays the minimum voltage measured at this point.
Average This field displays the average voltage measured at this sensor.
Threshold (Low) This field displays the lowest voltage limit at this sensor.
Threshold (Hi) This field displays the highest voltage limit at this sensor.
Status Normal indicates that the voltage is within an acceptable operating range at this
point; otherwise Abnormal is displayed.
Use this section of the screen to configure the hardware monitor threshold
settings.
New threshold
Apply Configure new threshold settings in the fields below and click Apply to use
them.
Temperature (Hi) Use these fields to configure the highest temperature limit at each sensor.
Temperature (Lo) Use these fields to configure the lowest temperature limit at each sensor.
