Chapter 52 ADSL Commands
IES-612-51A User’s Guide
366
The following example displays the line diagnostics results for DSL port 1.
The following table lists the line diagnostics test parameters that display, see the ITU-T’s
G.992.3 for more information.
Figure 249 Line Diagnostics Get 992.3 Command Example
ras> adsl linediag getld992_3 1
port: 1
number_of_subcarries: 256 32
hlinScale: 17024 32767
latn: 2.0 0.2
satn: 2.0 0.0
snrm: -0.0 6.0
attndr: 10398468 1152000
farEndActatp: 20.4 12.4
i li.rl li.im log(dB) QLN(dBm) SNR(dB)
0 N/A N/A N/A N/A N/A
1 N/A N/A N/A N/A N/A
2 N/A N/A N/A N/A N/A
3 N/A N/A N/A N/A N/A
4 N/A N/A N/A N/A N/A
5 N/A N/A N/A N/A N/A
6 0.31557 0.00796 -9.9 -120.5 8.5
7 0.43477 -0.31599 -5.3 -120.0 42.0
8 0.28313 -0.67576 -2.6 -119.5 44.5
9 -0.01016 -0.86645 -1.1 -119.0 46.5
10 -0.28423 -0.89969 -0.4 -118.5 51.5
11 -0.48750 -0.85403 -0.1 -118.0 52.0
12 -0.63495 -0.79630 0.2 -118.0 54.5
13 -0.75373 -0.75644 0.6 -117.5 56.5
14 -0.84457 -0.72510 1.0 -117.0 56.5
15 -0.89389 -0.68549 1.1 -116.5 56.5
16 -0.90713 -0.64631 1.0 -114.5 56.5
17 -0.91955 -0.63196 1.0 -116.0 57.0
18 -0.95053 -0.64860 1.3 -116.0 57.0
19 -0.97781 -0.67563 1.6 -115.5 57.0
20 -0.97161 -0.69211 1.6 -115.5 57.5
Table 97 Line Diagnostics Get 992.3 Command
LABEL DESCRIPTION
number_of_
subcarries
Discrete Multi-Tone (DMT) modulation divides up a line’s bandwidth into sub-
carriers (sub-channels) of 4.3125 KHz each.
The first number is the total number of DMT sub-carriers the DSL connection is
using. The second number indicates how many upstream DMT sub-carriers the
DSL connection is using.
hlinScale: The channel characteristics function is represented in linear format by a scale
factor and a complex number. These are the maximum upstream and
downstream scale factors used in producing the channel characteristics
function.
latn: This is the upstream and downstream Line Attenuation (in dB).
satn: This is the upstream and downstream Signal Attenuation (in dB).
