Chapter 6 Home and Port Statistics Screens
IES-612-51A User’s Guide
76
6.1.1 Ethernet Port Statistics Screen
Use this screen to display statistics about an Ethernet port. To open this screen, click an
Ethernet port’s number in the Home screen.
Media This field displays the type of media that this Ethernet port is using for a
connection. “-“ displays when the port is disabled or not connected.
Duplex This field displays whether the port is using half or full-duplex communication. “-
“ displays when the port is disabled or not connected.
Up Time This field shows the total amount of time in hours, minutes and seconds the
port’s connection has been up. “--:--:--“ displays when the port is disabled or not
connected.
The following fields are related to the xDSL ports.
xDSL This identifies the xDSL port. Click a port number to display that port’s statistics
screen. The
DSL Port Statistics Screen appears. See Section 6.1.2 on page 79 .
Status This field shows whether the port is connected (Up) or not (Down).
Mode This field shows which ADSL operational mode the port is set to use. “-“
displays when the port is not connected.
Up/Down stream This field shows the number of kilobits per second that a port is set to transmit
and receive.
Interleave/Fast This field shows the port’s ADSL latency mode (fast or interleave).
Up Time This field shows the total amount of time in hours, minutes and seconds the
port’s connection has been up. “-“ displays when the port is not connected.
The following fields and buttons apply to the whole screen.
Poll Interval(s)
Set Interval The text box displays how often (in seconds) this screen refreshes. You may
change the refresh interval by typing a new number in the text box and then
clicking Set Interval.
Stop Click Stop to halt system statistic polling.
Port
Clear Counter Select a port from the Port drop-down list box and then click Clear Counter to
erase the recorded statistical information for that port.
Reset Click this to set the Poll Interval(s) and Port fields to their default values and to
refresh the screen.
Table 5 Home (continued)
LABEL DESCRIPTION
