Chapter 19 Multicast VLAN
IES-612-51A User’s Guide
166
The following table describes the labels in this screen.
19.3 MVLAN Setup Screen
Use this screen to configure basic settings and port members for each multicast VLAN. To
open this screen, click Advanced Application, Multicast VLAN, MVLAN Setup.
Table 43 MVLAN Status
LABEL DESCRIPTION
MVLAN Setup Click MVLAN Setup to open the MVLAN Setup screen where you can
configure basic settings and port members for each multicast VLAN (see
Section 19.3 on page 166 ).
MVLAN Group Click MVLAN Group to open the MVLAN Group screen where you can
configure ranges of multicast IP addresses for each multicast VLAN (see
Section 19.4 on page 168 ).
The Number of
MVLAN This is the number of multicast VLAN configured on the IES-612-51A.
The first table displays the names of the fields. The subsequent tables show the
settings for each multicast VLAN.
Index This is a sequential value and is not associated with this multicast VLAN.
Name / VID This field shows the name and VLAN ID of this multicast VLAN.
1~12
ENET1-2 These fields display whether or not each port is a member of this multicast
VLAN. “V” displays for members and “-“ displays for non-members. You can
change these settings in the MVLAN Setup screen.
Status This field shows whether this multicast VLAN is active (Enable) or inactive
(Disable).
