Chapter 19 Multicast VLAN
IES-612-51A User’s Guide
169
MVLAN ID Select the VLAN ID of the multicast VLAN for which you want to configure a
range of multicast IP addresses.
Index Select the index number of the multicast VLAN group (the range of multicast IP
addresses) you want to configure for this multicast VLAN. If you want to change
the current settings, select an index number that already exists. If you want to
add a new multicast VLAN group, select an index number that does not exist.
Start Multicast IP Enter the beginning of the range of multicast IP addresses. The IP address must
be a valid multicast IP address, between 224.0.0.0 and 239.255.255.255.
End Multicast IP Enter the end of the range of multicast IP addresses. The IP address must be a
valid multicast IP address, between 224.0.0.0 and 239.255.255.255.
Apply Click Apply to save your changes to the IES-612-51A’s volatile memory. The
IES-612-51A loses these changes if it is turned off or loses power, so use the
Config Save link on the navigation panel to save your changes to the non-
volatile memory when you are done configuring.
Cancel Click Cancel to begin configuring the fields afresh.
MVLAN ID Select the VLAN ID of the multicast VLAN for which you want to look at or
remove the multicast IP addresses currently added to it.
Name This field displays the name of this multicast VLAN.
State This field shows whether this multicast VLAN is active (Enable) or inactive
(Disable).
Entry Index This field displays the index number of each multicast VLAN group (the range of
multicast IP addresses) configured for this multicast VLAN.
Start Multicast IP This field displays the beginning of this range of multicast IP addresses.
End Multicast IP This field displays the end of this range of multicast IP addresses.
Select Select this, and click Delete to remove the multicast VLAN group.
Delete Click this to remove the selected multicast VLAN groups.
Cancel Click Cancel to begin configuring the fields afresh.
Table 45 MVLAN Group (continued)
LABEL DESCRIPTION
