Chapter 31 ACL
IES-612-51A User’s Guide
218
31.3 ACL Profile Setup Screen
Use this screen to set up ACL profiles. To open this screen, click Advanced Application,
ACL, ACL Profile Setup.
Figure 109 ACL Profile Setup
The following table describes the labels in this screen.
Table 69 ACL Profile Setup
LABEL DESCRIPTION
ACL Setup Click ACL Setup to open the screen where you can assign ACL profiles to
PVCs (see
Section 31.2 on page 216 ).
ACL Profile Map Click ACL Profile Map to open the screen where you can look at which ACL
profiles are assigned to which PVCs (see
Section 31.4 on page 219 ).
