Chapter 13 xDSL Port Setup
IES-612-51A User’s Guide
119
Select
Delete Do the following to remove one or more PVCs.
1 Select a PVC’s Select radio button.
2 Click Delete.
3 Click OK if you want to remove the PVC from other ports. Click
Cancel to only remove the one you selected.
Figure 50 Basic Setting, xDSL Port Setup, VC Setup, Delete
4 If you clicked OK, the following screen appears.
5 Select to which ports you want to copy the settings. Use All to
select every port. Use None to clear all of the check boxes.
6 Click Apply to delete the channels.
Figure 51 Select Ports
Table 21 VC Setup (continued)
LABEL DESCRIPTION
