Chapter 15 xDSL Line Data
IES-612-51A User’s Guide
139
Figure 62 xDSL Performance
The following table describes the labels in this screen.
Table 30 xDSL Performance
LABEL DESCRIPTION
Line Rate Click Line Rate to display an ADSL port’s line operating values (see Section
15.1 on page 137 ).
Line Data Click Line Data to display an ADSL port’s line bit allocation (see Section 15.3 on
page 140 ).
Port Use this drop-down list box to select a port for which you wish to view
information.
Refresh Click Refresh to display updated information.
Port Name This section displays the name of the port.
Performance (since
last link up)
