Chapter 53 Virtual Channel Management Commands
IES-612-51A User’s Guide
380
This command creates a PPVC.
The following example creates a PPVC with VPI 8 and VCI 35 for port 5. The PPVC uses llc
encapsulation and default VID 25. Any frames received without an IEEE 802.1p priority tag
will be assigned a priority of 3. The IES-612-51A uses this PVC channel internally. This PVC
is not needed on the subscriber’s device.
53.4.2 PPVC Member Set Command
Syntax:
ras> adsl ppvc member set
where
= The VCI setting can be 32 to 65535 if the vpi is 0 or 1 to
65535 if the vpi is not 0. This PVC channel is for internal
use. The operator does not need to create this PVC on the
subscriber’s device (the CPE).
= The type of encapsulation: llc, vcmux
= Type a PVID (Port VLAN ID) to assign to untagged frames
received on this PPVC.
= This is the priority value (0 to 7) to add to incoming frames
without a (IEEE 802.1p) priority tag.
Figure 263 PPVC Set Command Example
ras> adsl ppvc set 5 8 35 llc 25 3
= The port(s) of the PPVC.
You can specify a single DSL port <1>, all DSL ports <*>
or a list of DSL ports <1,3,5>. You can also include a range
of ports <1,5,6~10>.
= The VPI of the PPVC.
= The VCI of the PPVC. This PVC channel is for internal use.
The subscriber does not need to create this PVC.
= The VPI of the individual PVC that you are adding to the
PPVC. The VPI setting can be 0 to 255.
= The VCI of the individual PVC that you are adding to the
PPVC. The VCI setting can be 32 to 65535 with a VPI of 0
or 1 to 65535 if the VPI is not 0. The subscriber’s device
must create this PVC.
DS vcprofile = Assign a VC profile to use for this channel’s downstream
traffic shaping.
