Chapter 18 Static Multicast
IES-612-51A User’s Guide
164
MAC Address This is the multicast MAC address.
1~12 These fields display the static multicast group membership status of the DSL
ports.
“V” displays for members and “-“ displays for non-members.
Click a DSL port’s status to change it (clicking a “V” changes it to “-“ and vise
versa).
Join All Click Join All to make all of the DSL ports members of the static multicast
group.
Leave All Click Leave All to remove all of the DSL ports from the static multicast group.
Delete Click Delete to remove a static multicast group.
Adding new entry
Add Type a multicast MAC address in the field, and click the Add button to create a
new static multicast entry. Multicast MAC addresses must be
01:00:5E:xx:xx:xx , where x is a “don’t care” value. For example,
01:00:5E:10:10:10 is a valid multicast MAC address.
Clicking Add saves your changes to the IES-612-51A’s volatile memory. The
IES-612-51A loses these changes if it is turned off or loses power, so use the
Config Save link on the navigation panel to save your changes to the non-
volatile memory when you are done configuring.
Table 42 Static Multicast (continued)
LABEL DESCRIPTION
