IES-612-51A User’s Guide
75
C
H A P T E R
6
Home and Port Statistics
Screens
This chapter describes the Home (status), Port Statistics, and RMON screens.
6.1 Home Screen
The Home screen of the web configurator displays a port statistical summary with links to
each port showing statistical details.
To open this screen, click Home in any web configurator screen.
Figure 31 Home
The following table describes the labels in this screen.
Table 5 Home
LABEL DESCRIPTION
System up Time This field shows how long the system has been running since the last time it
was started.
The following fields are related to the Ethernet ports.
ENET This field displays the number of the Ethernet port. Click a port number to
display that port’s statistics screen. The
Ethernet Port Statistics Screen appears.
See Section 6.1.1 on page 76 .
Status This field displays whether the Ethernet port is connected (Up) or not (Down).
Port Name This field displays the name of the Ethernet port.
