Chapter 53 Virtual Channel Management Commands
IES-612-51A User’s Guide
395
This command displays statistics about PPPoA-to-PPPoE PVC activity.
The following example displays the statistics for port 1.
Figure 286 PAE PVC Counter Command Example
Each value is described below.
=
The VPI of the PAE PVC.
=
The VCI of the PAE PVC.
ras> adsl paepvc counter 1
pvc 1-1/33
tx rx
---------------- ----------------
ppp lcp config-request : - 0
ppp lcp echo-request : - 0
ppp lcp echo-reply : - 0
pppoe padi : 0 -
pppoe pado : - 0
pppoe padr : 0 -
pppoe pads : - 0
pppoe padt : 0 0
pppoe srvcname error : - 0
pppoe ac system error : - 0
pppoe generic error : 0 0
tx/rx
=
The values in these columns are for packets transmitted (
tx
)
or received (
rx
) by the IES-612-51A.
ppp lcp config-
request
=
The number of config-request PDUs received by the IES-
612-51A from the CPE (client) device.
ppp lcp echo-
request
=
The number of echo-request PDUs received by the IES-612-
51A from the CPE (client) device.
ppp lcp echo-
reply
=
The number of echo-reply PDUs received by the IES-612-
51A from the CPE (client) device.
pppoe padi
=
The number of padi PDUs sent by the IES-612-51A to the
BRAS.
pppoe pado
=
The number of pado PDUs sent by the BRAS to the IES-
612-51A.
pppoe padr
=
The number of padr PDUs sent by the IES-612-51A to the
BRAS.
pppoe pads
=
The number of pads PDUs sent by the BRAS to the IES-
612-51A.
pppoe padt
=
The number of padt PDUs sent and received by the IES-
612-51A.
