Chapter 27 RFC 2684 Routed Mode
IES-612-51A User’s Guide
199
The following table describes the labels in this screen.
27.4 RPVC Arp Proxy Screen
Use this screen to view the Address Resolution Protocol table of IP addresses of CPE devices
using 2684 routed mode and configure how long the device is to store them.
To open this screen, click Advanced Application, 2684 Routed Mode, RPVC ARP Proxy.
Table 60 2684 Routed Domain
LABEL DESCRIPTION
RPVC ARP Proxy Click RPVC ARP Proxy to go to the screen where you can view the Address
Resolution Protocol table of IP addresses of CPE devices using 2684 routed
mode and configure how long the device is to store them (see
Section 27.4 on
page 199 ).
Routed Gateway Click Routed Gateway to go to the screen where you can configure gateway
settings (see
Section 27.5 on page 200 ).
Routed PVC Click Routed PVC to go to the screen where you can configure routed PVC
settings (see
Section 27.2 on page 196 ).
Port Use this drop-down list box to select a port for which you wish to configure
settings.
VPI Type the Virtual Path Identifier for this routed PVC.
VCI Type the Virtual Circuit Identifier for this routed PVC.
IP Enter the subscriber’s CPE LAN IP address in dotted decimal notation.
NetMask The bit number of the subnet mask of the subscriber’s IP address. To find the bit
number, convert the subnet mask to binary and add all of the 1’s together. Take
“255.255.255.0” for example. 255 converts to eight 1’s in binary. There are three
255’s, so add three eights together and you get the bit number (24).
Add Click Add to save your changes to the IES-612-51A’s volatile memory.
The IES-612-51A loses these changes if it is turned off or loses power, so use
the Config Save link on the navigation panel to save your changes to the non-
volatile memory when you are done configuring.
Cancel Click Cancel to start configuring the screen again.
Index This field displays the number of the routed PVC.
Port This field displays the number of the DSL port on which the routed PVC is
configured.
VPI This field displays the Virtual Path Identifier (VPI) The VPI and VCI identify a
channel on this port.
VCI This field displays the Virtual Circuit Identifier (VCI). The VPI and VCI identify a
channel on this port.
IP This field displays the subscriber’s IP address.
NetMask This field displays the bit number of the subnet mask of the subscriber’s LAN IP
address.
Delete Select an entry’s Delete check box and click Delete to remove the entry.
Clicking Delete saves your changes to the IES-612-51A’s volatile memory.
The IES-612-51A loses these changes if it is turned off or loses power, so use
the Config Save link on the navigation panel to save your changes to the non-
volatile memory when you are done configuring.
Cancel Click Cancel to start configuring the screen again.
