Chapter 41 Commands Summary
IES-612-51A User’s Guide
260
timeserver set
[nosync]
Sets the time service protocol,
time server’s IP address and the
device’s time zone. H/H
timeserver set
>0100~1200]>
[nosync]
Sets the time service protocol,
time server’s IP address and the
device’s time zone. H/H
timeserver sync Retrieves the date and time from
the time server. H/H
log show Displays the device’s logs. M/L
log clear Clears the device’s logs. H/H
wdog show Displays the current watchdog
firmware protection feature status
and timer. H/~
wdog set Sets the watchdog count. 0 turns
the watchdog off. H/~
monitor show Displays the hardware monitor’s
statistics. L/L
monitor enable Turns the hardware monitor on. H/H
monitor disable Turns the hardware monitor off. H/H
monitor vlimit Sets the maximum () or
minimum () voltage at the
specified voltage sensor. You can
specify a voltage with up to three
digits after a decimal point (0.941
for example).
Normal voltage at each sensor:
Idx: 1=1.2v, 2=1.8v, 3=3.3v, 4=24v H/H
monitor tlimit Sets the maximum () or
minimum () temperature at
the specified temperature sensor.
You can specify a temperature
with up to three digits after a
decimal point (-50.025 for
example).
Temperature sensor locations:
Idx: 1=DSL, 2=CPU, 3=HW
monitor H/H
user online Displays online user info. M/~
user enable Turns on the specified user name
of multi-login. H/H
user disable Turns off the specified user name
of multi-login. H/H
user set Creates or edits the password and
privilege level of the specified
user name. H/H
user delete Removes the specified user name
of multi-login. H/H
Table 88 Commands (continued)
CLASS COMMAND PARAMETERS DESCRIPTION P
