Chapter 45 IEEE 802.1Q Tagged VLAN Commands
IES-612-51A User’s Guide
301
where
This command sets the priority of incoming frames with an IEEE 802.1Q VLAN tag.
The following example sets a priority of three for frames (with an IEEE 802.1Q VLAN tag)
that come in on DSL port 2.
45.4.4 VLAN Set Command
Syntax:
ras> switch vlan set :|X|N> [:|X>
...][name]
where
This command adds or modifies an entry in the static VLAN table. Use the switch vlan
show command to display your configuration. An example of a configuration is shown next.
= You can specify a single port: <1>, all ports: <*>, a list of
ports: <1,3,enet1>, you can also include a range of ports:
<1,5,6~10,enet1,enet2>.
= This is the priority value (0 to 7) to use for incoming frames
with an IEEE 802.1Q VLAN tag.
Figure 152 VLAN CPU Set Command Example
ras> switch vlan priority 2 3
= The VLAN ID [1 – 4094].
= You can specify a single port: <1>, all ports: <*>, a list of
ports: <1,3,enet1>, you can also include a range of ports:
<1,5,6~10,enet1,enet2>.
| = The stands for a fixed registrar administration control
flag and registers a to the static VLAN table with
.
For a fixed port, you also have to specify , the tag
control flag.
has the device add an IEEE 802.1Q tag to frames going
out through this port(s).
has the device send frames out through this port(s)
without an IEEE 802.1Q tag.
|X|N> = This is the registrar administration control flag.
stands for forbidden and blocks a from
joining the static VLAN table with .
stands for normal and confirms registration of the
to the static VLAN table with . This is used
in GVRP applications.
[name] = A name to identify the SVLAN entry.
