ZyXEL Communications IES-612-51A - Manual (Page 386)

Chapter 53 Virtual Channel Management Commands
IES-612-51A User’s Guide
386
This command displays the gateway IP addresses that are configured for use with 2684
routed mode traffic.
The following is an example.
53.7.4 RPVC Gateway Delete Command
Syntax:
ras> adsl rpvc gateway delete
where
This command removes a gateway IP address that the device was set to use for 2684 routed
mode traffic.
The following example has the device remove a 2684 routed mode traffic gateway entry for IP
address 192.168.10.102.
53.7.5 RPVC Set Command
Syntax:
ras> adsl rpvc set
/
where
Figure 272 RPVC Gateway Show Command Example
ras> adsl rpvc gateway show
gateway ip vid
--------------- ----
192.168.10.102 1
= The IP address of the gateway to which you no longer want
the device to send the traffic that the system receives from
this PVC. Enter the IP address in dotted decimal notation.
Figure 273 RPVC Gateway Delete Command Example
ras> adsl rpvc gateway delete 192.168.10.102
= The port(s) of the RPVC.
You can specify a single DSL port <1>, all DSL ports <*>
or a list of DSL ports <1,3,5>. You can also include a range
of ports <1,5,6~10>.
= The VPI of the RPVC.
= The VCI of the RPVC.
DS vcprofile = Assign a VC profile to use for this channel’s downstream
traffic shaping.
