Chapter 53 Virtual Channel Management Commands
IES-612-51A User’s Guide
379
This command allows the configuration of a PVC (permanent virtual circuit) for one or a
range of DSL ports.
The following example sets a PVC on DSL port 1 with VPI 1, VCI 34, default VID 100
priority 3. It sets the “platinum” profile for downstream traffic shaping and a VC profile
named “plus” for upstream traffic policing.
53.3.3 PVC Delete Command
Syntax:
ras> adsl pvc delete
where
This command deletes the specified PVC channel.
53.4 Priority-based PVCs
A PPVC (Priority-based PVC) allows you to give different priorities to PVCs that are
members of the same VLAN.
The IES-612-51A uses eight priority queues (also called levels) for the member PVCs. The
system maps frames with certain IEEE 802.1p priorities to a PVC with a particular priority
queue. See
for the factory default mapping.
Use these commands to configure PPVCs and add and remove member PVCs.
53.4.1 PPVC Set Command
Syntax:
ras> adsl ppvc set
where
Figure 262 PVC Set Command Example
ras> adsl pvc set 1 1 34 100 3 platinum,plus
=
You can specify a single DSL port <1>, all DSL ports <*>
or a list of DSL ports <1,3,5>. You can also include a range
of ports <1,5,6~10>.
[
=
The VPI and VCI of an individual PVC.
=
You can specify a single DSL port <1>, all DSL ports <*>
or a list of DSL ports <1,3,5>. You can also include a range
of ports <1,5,6~10>.
=
The VPI setting can be 0 to 255.
