Chapter 54 ACL Commands
IES-612-51A User’s Guide
402
Figure 291 ACL Profile Show Command Example
54.2 ACL Assignment Commands
Use these commands to apply ACL profiles to PVCs.
54.2.1 ACL Assignment Set Command
Syntax:
ras> switch acl set
where
This command allows you to apply an ACL profile to the specified port(s). You can apply up
to eight profiles to a subscriber port.
The following example applies the ACL profile “test” to a PVC.
Figure 292 ACL Assignment Set Command Example
54.2.2 ACL Assignment Delete Command
Syntax:
ras> switch acl delete
ras> switch acl profile show test
profile test:
rule:
vlan :10
priority:2
action:
rpri :7
rate :1000
= The port number of the PVC. You can specify a single DSL
port <1>, all DSL ports <*> or a list of DSL ports <1,3,5>.
You can also include a range of ports <1,5,6~10>.
= The VPI of the PVC.
= The VCI of the PVC.
= The name of the ACL profile.
ras> switch acl set 1 0 33 test
