Table 2.9.2 (3/5) Technial Functions
T.F.
No.
Name of Function The Display Shows
18 DIS bit 32
21 NL equalizer
22 Modem attenuator
20 Off-hook bypass
17 T2, timeout value
17:T2 TIMER *100MS
[ X ] YES(
←
) NO(
→
) To 18: DIS BIT32
X: 001 - 255
→
17:T2 TIMER *100MS
[ ] ENTER 000-255
17:T2 TIMER *100MS
[059] YES(
←
) NO(
→
)
3-digit timer entered.
→
→
18:DIS BIT32
[ X ] YES(
←
) NO(
→
)
→
Setting (Toggle)
X: OFF ON
→
←
19 Error criterion
19:ERR. CRITERION
[ X ] YES(
←
) NO(
→
) To 20: OFF HOOK
BYPASS
X: 00 - 99% →
19:ERR. CRITERION
[00] ENTER 00-99
19:ERR. CRITERION
[10] YES(
←
) NO(
→
)
2-digit timer entered.
→
→
(Example)
(Example)
20:OFF HOOK BYPASS
[ X ] YES(
←
) NO(
→
)
→
Setting (Toggle)
X: OFF ON
→
←
21:NL EQUALIZER
[ X ] YES(
←
) NO(
→
)
→
Setting
X:0 KM 1.8 KM → →
→ 3.6 KM → 7.2 ΚΜ → 0 ΚΜ
22:ATTENUATOR
[ X ] YES(
←
) NO(
→
)
→
Setting
X:0 DB → 1 DB →
2 DB → • • • • • → 15 DB → 0
DB → ••••
23 T/F tone attenuator
(for TEL/FAX switch) 23:T/F TONE ATT.
[ X ] YES(
←
) NO(
→
)
→
Setting
X:0 DB → 1 DB →
2 DB →
• • • • •
→ 15 DB → 0
DB → ••••
–
