40055101TH Rev.4 254 /
7.1.15 Tone (TEL/FAX) Send Test
Start
No
Pseudo-Ring Back Tone
signal appears
across L1 and L2?
Yes
MF signal appears across CN10-A8, B8
(S) and CN10-A12, B12 (0V) of MCNT board?
Replace MCNT Board.
Replace WN5 Board.
Solved?
Replace MCNT Board.
Signal route:
CN3-15, 16
→
T1-3, 1
→
CN1-3, 4
End
No
Yes
Yes
No
Return to section 7.1.1
Connect oscilloscope probe
across the line terminals
L1 and L2.
Perform TONE (TEL/FAX)
SEND TEST. (See 6.12.)
Possible cause:
CML signal
Signal route:
IC8-26 to 33 (AD0 to AD7)
→
IC8-1,
IC12-7 (S)
→
CN10-A8, B8 (S)
Note: The pseudo-ring back tone is sent to the
telephone line for TEL/FAX automatic
switching.
