Take out the toner cartridge from the damp proof bag, shake it five or six times as shown in the
illustration to eliminate the toner deflection, and peel off the seal gently.
•
Ensure that the plastic tab on the right-hand side of the toner cartridge recess lines up with the
groove on the toner cartridge.
•
Press down on both ends to make sure the cartridge is fully seated.
Figure 2.5.2.3 Toner Cartridge Installation (3)
Figure 2.5.2.4 Toner Cartridge Installation (4)
Toner cartridge
Blue tab
FX-050VP-C2-009
FX050VP-C2-008
Seal
Toner cartridge
