40055101TH Rev.4

195 /

c)

Release the gear by unlocking the
latch on the Lower Base.

d)

Lift the right side of the Transfer
Roller and shift rightwards, then
pull it out from the Lower Base.

(2)

Reassembly procedure

Reverse the disassembly procedures.

(FX050-C4-026)

Lower Base

Latch

Gear

Transfer Roller
