40055101TH Rev.4 155 /
4.1.2 Tools
Table 4.1.1 shows the tools required for the replacement of parts such as circuit boards and mechanical units.
Table 4.1.1 Tools
No. Service tools
Philips screw driver (L)
Q'ty Remarks
Philips screw driver (M)
Flat screw drivers (S)
Philips screw driver (S)
Radio pliers
Nippers
Multimeter
1
2
3
4
5
6
7
1
1
1
1
1
1
1 Short-ciucuit test
4.1.3 How to Disassemble and Reassemble
This section explains how to disassemble and reassemble the fax.
• Figure 4.2 shows the disassembly procedure flow as generalization.
• The detailed disassembly procedure is explained from sub-section 4.1.3.1 to 4.1.3.18.
