40055101TH Rev.4 514 /
OPC drum
Charge roller
Developing blade
Sponge roller
Developing roller
2 The toner applied to the developing roller is thin-coated by the developing blade.
3 A toner adheres to the exposure part of the OPC drum in the contact part between the OPC drum and
developing roller. This causes the electrostatic latent image to be changed to a visible image.
(5) Development
The electrostatic latent image on the surface of the OPC drum is changed to a visible toner image by
applying a toner to it. Development is performed in the contact part between the OPC drum and developing
roller.
1 The sponge roller negatively charges a toner and applies it to the developing roller.
