Section 3 PRINTER ASSEMBLY 1/2
Rev.
No.
Oki parts Number
Description
Q’ty
Remarks
1
2PA4120-1214G001
Stacker Cover Assy.
1
2
4PB3517-1567P001
Guide Wire
1
3
4YB4120-1117P001
Pulse Motor (Main)
1
4
4YB4120-1118P001
Pulse Motor (Resist)
1
5
4PP4083-2593P001
Idle Gear (Z90/16)
2
6
3PP4083-6076P001
Reduce Speed Gear
1
8a
2YX4120-1128G001
Fusing Unit Assy. (120V)
1
ODA
8b
2YX4120-1128G002
Fusing Unit Assy. (230V)
1
Except ODA
9
3PA4122-1295G001
Hopping Roller Assy.
1
10
4PP4083-6022P002
Bearing
5
11
4PP4083-6086G001
Toner Sensor (Adhesive)
1
12
4PP4083-6083P001
Sensor Plate (Inlet)
3
13
4PB4083-6024P001
One-way Clutch Gear
2
14
4PP4083-6080P001
Idle Gear (Z36)
1
15
3PP4083-6054P001
Reset Lever (R)
1
16
4PP4083-6081P001
Idle Gear (Z22)
1
17
3PB4083-6030P001
Resistration Roller
1
18
4PP4083-6042P001
TR Gear
1
2
19
3YB4083-7640P002
Transfer Roller
1
20
3PB4083-6064P002
Back-up Roller
1
21
4PP4083-6052P001
Bush
2
22
4PP4083-6065P001
Bias Spring
2
23
1PP4083-6035G001
Lower Base Sub Assy.
1
24
3PP4083-6058P001
Switch Arm
1
25
3PP4083-6053P001
Reset Lever (L)
1
26
4PP4083-6057P001
Reset Spring
1
27
4PB4083-6197P001
Dumper
1
28
4PP4083-6191G001
Dumper Arm
1
29
4PA4083-6025G001
Sensor Plate (Outlet)
1
30
2PA4120-1129G001
Exit Roller Assy.
1
