40055101TH Rev.4 568 /
Section 11 PRINTER BASE FRAME UNIT 2/2
Rev. No. Oki parts Number Description Q’ty Remarks
31a 3PB4083-1140P001 Resistration Roller 1
31b 40457001 Resistration Roller 1 For CHN
4 32 41802101 Film-Guide_F 1
33 3PP4083-1151P001 Gear T 1
34a 3YB4083-1150P002 Transfer Roller 1
34b 40456901 Transfer Roller 1 For CHN
35 4PP4083-1136P001 Bias Spring (L) (Back UP Roller) 1
36 3PP4083-1161P001 Bearing BU (Back Up Roller) 2
37 3PB4083-1160P002 Pressure Roller B (Back Up Roller) 1
38 3PP4083-1233P001 Paper Guide (R) 1
39 3PP4083-1232P001 Paper Guide (L) 1
40 1PP4083-1231P001 Paper Holder 1
41 3PP4083-1192P001 Paper Sensor Exit 1
4 42 41802001 Spring-Hopper_F 1
47 4PP4083-1137P001 Bias Spring (R) (Back Up Roller) 1
49 1PP4083-1241P001 Sheet Guide 1
51a 1YX4083-1200G001 Heat Assy. 1 120V
51b 1YX4083-1200G002 Heat Assy. 1 230V
52 40034001 Stopper Spring 1
53 4PB4091-6047P001 Caution Label (TR) 1 230V
