Figure 4.1 (2/2) OKIOFFICE44/OKIFAX 4100 Disassembly Procedure Flow
Open the OPE
Panel Assembly
Heat
Assembly
(4.1.3.15)
Plessure Roller B
(Backup Roller)
(4.1.3.16)
Paper Sensor E
Paper Sensor Exit
Toner Sensor Assy.
(4.1.3.18)
Plate-Side M
Gear-Idle
(4.1.3.12)
+
Hopping
Shaft Assy.
(4.1.3.17)
Separation
Plate
(4.1.3.3)
Printer Unit
Assembly
(4.1.3.3)
Drive shaft E
and Eject Roller
(4.1.3.14)
High-voltage
Power Supply
(TLHV/OLHV)
(4.1.3.10)
ID Unit
(4.1.3.9)
Transfer roller
(4.1.3.9)
Cover Rear
(4.1.3.2)
Cover NCU
(4.1.3.2)
Cover Main
(4.1.3.2)
Holder Assembly
(4.1.3.10)
Open the Cover
Assembly-Top
Registration
Roller
(4.1.3.13)
Printer Unit
Start
