40055101TH Rev.4 128 /
Operations:
TECH. PROGRAMMING
YES( ← /1-4) NO( → )
To bring the LCD up to the desired message,
press SELECT FUNCTION key once and COPY
key twice in the standby mode. (In case of
no message in memory)
The display shows:
Press key. ←
1: LOCAL TEST
YES( ← ) NO( → /1-4)
←
1: SELF DIAGNOSIS
YES( ← ) NO( → /1-8)
1: SELF DIAGNOSIS
EXCUTING
CPU PROG1 PROG2
XXXX XXXX XXXX
1: SELF DIAGNOSIS
PRINTING
←
←
Press key.
←
Press key for cheking and test printing.
(An example of printed data is shown in
Figure 2.9.4) ←
Version indication
3 SEC LATER
2.9.10 Off-line Tests
(1) Purpose
Activate self-diagnosis which includes:
•
Print test
• CPU-ROM version printing
• CPU-RAM check
• PROG version printing
• LANGUAGE version printing
• DEFAULT version printing
• RAM check
• RAM check (memory board: optional)
• PC-I/F version printing (optional)
(2) Procedure
