40055101TH Rev.4 567 /
Section 11 PRINTER BASE FRAME UNIT 1/2
Rev. No. Oki parts Number Description Q’ty Remarks
1 2PP4083-1502G001 Base Frame Assy. 1
3 3PP4083-1191P001 Paper Sensor E 2
4 4 40721301 Separator Assy. 1
4
6 4PP4083-1246P001 Compression Spring S 1
7 3PA4083-1193G001 Toner Sensor Assy. 1
8 4PB4083-1172P001 Pulse Motor (Main) 1
9a 4YA4083-1600G002 Ep Unit 1 For ODA
9b 4YA4083-1600G003 Ep Unit 1 For OEL/OKI-INT
10a 40035001 Toner Cartridge Unit 1 For ODA
10b 4YA4083-1450G003 Toner Cartridge Unit 1 For OEL/OKI-INT
11 4PB4083-1129P001 Hopping Roller 1
12 3PP4083-1128P001 Roller Holder (Hopping Roller) 1
13 3PB4083-1127P001 Magnet H (Hopping Shaft) 1
14 3PA4083-1133G001 Hopping Shaft Assy. 1
15 NK2-10-SUS Knock Pin 1
16 4PP4083-1143P001 Idle Gear R 1
17 3PP4083-1184P001 Idle Gear 2R 1
18 3PP4083-1142P001 Gear R 1
19 2PP4083-1181P001 Idle Gear M 1
20 3PP4083-1189P001 Earth Plate A 1
21 3PP4083-1188P001 Slide Plate M 1
22 3PP4083-1182P001 Idle Gear P 2
23 3PP4083-1183P001 Idle Gear 3R 1
24 4PP4083-1165P001 Tension Plate 1
25 3PP4083-1185P001 Idle Gear Heat 1
26 4PP4083-1186P001 Idle Gear E (A) 1
27 3PP4083-1187P001 Idle Gear E (B) 1
28 3PP4083-1170P001 Drive Shaft E (Eject) 1
29 40074601 Eject Roller 2
30 3PP4083-1141P001 Resistration Bearing 4
