Section 1 CABINET ASSEMBLY
Rev.
No.
Oki parts Number
Description
Q’ty
Remarks
1a
1PA4120-1079G001
Document Hopper Assy.
1
OKI
1b
1PA4120-1079G004
Document Hopper Assy.
1
TN
2a
2PP4120-1084P001
Sub-Hopper
1
OKI
2b
2PP4120-1084P004
Sub-Hopper
1
TN
3a
2PP4120-1091P001
NCU Cover
1
OKI
3b
2PP4120-1091P004
NCU Cover
1
TN
4a
1PP4120-1089P001
Main Cover
1
OKI
4b
1PP4120-1089P004
Main Cover
1
TN
5a
2PA4083-6130G001
Manual Feed Guide Assembly
1
OKI
5b
40051902
Guide Assy,-Manual Feed
1
TN
6a
40044501
Board-UNC 1
US
(050VP)
6b
40044401
Board-FN5
1
UK, France
6c
40044101
Board-DN5
1
GER/TN
4
6d
40044303
Board-WN5
1
CHN
6e
40044307
Board-WN5
1
OEL/AUS/ENC
6f
40044502
Board-UNC
1
US (FX-175VP)
4
6g
40044305
Board-WN5
1
OKI-INT
7a
40274601
Board-S34
1
for OKIFAX 5600/5500
7b
40274602
Board-S34
1
Only for 5500/5600VE machine.
(Only for Board-E17)
8
3PP4120-1088P001
Partition Plate
1
9a
1PP4120-1090P001
Rear Cover
1
9b
1PP4120-1090P004
Rear Cover
1
TN
9c
40545301
Rear Cover
1
For 5300ENC
10
1PP4120-1093P001
Stacker
1
11
Screw
12
Screw
13
Screw
14
4PB4120-1136P001
Knob Screw
2
15
4PP4120-1161G001
Assist Guide
3
16
223A7010P0003
Dust Cover
1
Note 1
17
40275501
Plate-guard
1
Note 1: Required number of this part is arrenged by each country.
