Oki B4100 User Manual
Page 152
40055101TH Rev.4
152 /
3.4
Overall Dimension and Mechanical Structure of OKIOFFICE44/OKIFAX 4100
Figure 3.4.1 Overall Dimension and Mechanical Structure
Document
Paper
EP drum
Roller - Heater
Paper exit
ID unit
LED head
Scanner block
Roller - ADF
Separation rubber
OPE board
Roller - Scan
Document exit
Manual paper feeder inlet
Image sensor
Roller - Hopping
Printer block
HVPS board
MPSU board
CNT board
Memory board
(option)
CTR board
(option for OKIFAX4100)
NCU board
