7
Troubleshooting
If you cannot print when the printer is
connected via the 1394 Interface Unit
or error messages appear, follow the
procedure:
A
Make sure the 1394 Interface Unit
is installed properly.
B
Make sure the IEEE 1394 cable is
connected properly.
C
Restart the computer.
If the problem still exists, go to step
D .
D
Disconnect all the IEEE 1394 ca-
bles from the computer.
E
If you uninstall the printer driver
when the printer is connected to a
computer with “SCSI print”, the
printer driver may not be unin-
stalled properly. To uninstall the
driver properly, use the IEEE 1394
Printer Removal Utility on the
CD-ROM that comes with the
printer.
Stored in: CD-ROM labeled "Print-
er Drivers and Utilities"\DRIV-
ERS\UTILITY\1394\
Note
❒ For more information about the
IEEE 1394 Printer Removal Util-
ity, see the README file in the
same folder as the program.
F
Restart the computer.
- - - -1394 Interface Unit
specification
❖ Operating System:
Windows 2000 Service Pack 1 or
later (when connecting with SCSI
print)
Windows Me (when connecting
with IP over 1394)
❖ Interface:
IEEE Std 1394-1995 compliant,
IEEE Std 1394a-2000 compliant
❖ Interface Connector:
IEEE 1394 (6-pin
× 2)
❖ Data Transmission:
400 Mbps (maximum)
❖ Required cable:
1394 interface cable (6-pin x 4-pin,
6-pin x 6-pin)
Important
❒ You cannot plug devices togeth-
er to create loops.
❒ Do not use a cable more than 4.5
meters (14.8 feet) long.
❖ Connectable number of devices in a
bus:
Maximum 63
❖ Allowed cable hops in a bus:
Maximum 16
❖ Length of cable:
4.5 meters (maximum per hop)
❖ Power supply:
Non power supply
Cable Power repeated (IEEE1394a-
2000 compliant)
❖ Power repeat:
IEEE Std 1394a-2000 compliant
