Removing Misfed Paper
83
5
FFFF
If you can see the paper from the
right of the printer, remove it.
GGGG
Turn the blue knob B counter-
clockwise (
A A A A), and then remove
the misfed paper from inside the
right cover (
B B B B).
HHHH
Close the covers in the following
order:
• The right cover
• The Duplex Unit
• The Bypass Tray
• The front cover
• The output feeder cover
IIII
Open the covers of the Bridge
Unit (
A A A A, and then remove the
misfed paper (
B B B B).
JJJJ
Close the cover of the Bridge
Unit.
B
1
2
