Setting up as a print server, P.51 “setting up as a print server – Ricoh AP4510 User Manual
Page 291
NetWare 4.x, 5/5.1 - Advanced Settings
51
4
Setting Up as a Print Server
Important
❒ You can set up the print server using the NDS or Bindery mode in NetWare
4.x, 5/5.1. The following procedure is for setting up the print server using the
NDS mode in NetWare 4.1. When you set up the print server using the Bind-
ery mode, use the NIB Setup Tool Wizard.
Note
❒ If you use Pure IP in NetWare 5/5.1, follow the procedure on p.53 “Using
Pure IP in the NetWare 5/5.1 environment”.
AAAA
Log on to the file server as an Admin or an Admin equivalent.
BBBB
Run the NIB Setup Tool.
Reference
⇒ p.40 “Running the NIB Setup Tool”
CCCC
Click [Property Sheet] and click [OK].
DDDD
Click [IPX protocol].
EEEE
Click the IPX address of the Network Interface Board which is to be config-
ured, and then click [Next >].
Note
❒ If you do not know which Network Interface Board you are configuring,
see the network configuration page to check the MAC address (Network
Address).
FFFF
Make sure that the MAC address and IPX address are correct, and then click
[Finish]
.
The [NIB Setup Tool] window appears.
GGGG
Click [Configure].
The property sheet appears.
HHHH
Click the [General] tab, and then type the name of the print server into the
[Device Name]
box.
IIII
Click the [NetWare] tab, and then make the following settings.
A
A
A
A In the [Print Sever Name:] box, type the name of the print sever.
B
B
B
B In the [File Sever Name:] box, type the name of the file sever in which a
print server is to be created.
Clicking [Browse], you can select a file server among those listed in the
[Browse]
dialog box.
