Ricoh AP4510 User Manual
Page 260
Windows 2000 Configuration
20
2
EEEE
Select the printer.
TCP/IP
A
A
A
A Click the printer you want to use, and then click [OK].
Note
❒ Printers that respond to an IP broadcast from the computer will be dis-
played. To print to a printer not listed here, click [Specify Address] and
then type the IP address or host name.
NetBEUI
A
A
A
A Click [NetBEUI].
A list of printers that can be printed by the NetBEUI protocol appears.
B
B
B
B Click the printer you want to use, and then click [OK].
Note
❒ Printers that respond to a broadcast from the computer will be displayed.
To print to a printer not listed here, click [Specify Address] and then type
the NetBEUI address. Make sure that the NetBEUI address is on the con-
figuration page. For information about the printing of the configuration
page, see "Printing a Configuration Page" in the Setup Guide. The Net-
BEUI address appears as "\\RNPxxxx\xxx" on the configuration page.
Type the printer's network path name in the form of "%%Computer
name\Share name". Do not type "\\" as head characters but "%%".
❒ You cannot print to printers beyond routers.
IPP
A
A
A
A Click [IPP].
The IPP setting dialog box appears.
B
B
B
B To specify the IP address of the printer, type "http://printer's-ip-ad-
dress/printer" or "ipp://printer's-ip-address/printer" in the [Printer URL]
field.
(Example IP address is 192.168.15.16)
http://192.168.15.16/printer
ipp://192.168.15.16/printer
C
C
C
C As necessary, type the names to distinguish the printer in [IPP Port Name].
Type a name different from those of any existing port names.
If you omit this, the address entered in [Printer URL] will be set as the IPP
port name.
